The Custom Set provides a large area for placing blocks of
different sizes. The block sizes can be
adjusted to any widths and heights.
These various blocks can be placed and aligned anywhere inside the quilt
center.
When designing with a Custom Set you can use all 3 layers. Layer 2 will allow you to float applique
elements and Layer 3 is for your quilting stitches. These layers allow us to
multiply your design possibilities.
One of the wonderful features of the Custom Set is the Quilt
Snap Grid. This grid allows blocks to snap for the best accuracy when layout a
custom set grid. Just like if you were
drawing on a piece of graph paper. This feature can be used in all 3 layers of
the Quilt Worktable. EQ7 gives you the
ability to change the Grid Snap Settings.
There are three grid snap settings that can be changed in
the Quilt
Worktable Options.
There is two ways to locate the Quilt Worktable Option you
can get there by clicking on the Quilt
> Quilt Worktable Options. Or by clicking on
the Quilt Worktable Options button (Button pictured below) found on the
project tool bar.
Under the Tools Options Click on Snap Settings, then under Grid Settings, you will
notice 3 checkboxes corresponding to the 3 buttons on the Graph Pad. Below are
the explanation of what the three checkboxes do.
|
Snap Grid Setting |
Show Grid (Custom
Set): allows you display the grid on a new Custom Set quilt.
The grid increments can be changed on your grid by using the
Grid Snap every: drop down arrow and
choosing a different increments. Please
note that the program can only “draw” so many grid lines on the quilt
layout. So if you don’t see grid lines
that doesn’t mean that they are not there.
|
Grid Snap Every |
Below show the grid
set up for every ¼” apart.
It’s recommended you turn on the Quilters Ruler just Click View > Quilters Rulers to put
a check next to it and this will turn on the ruler.
Once the Quilters Ruler you may want to verify your Quilters
Ruler Origins in the Quilters Worktable Options. Under Tool
Options > Click View Setting > Select
Top
left Corner of Quilt’s center layout so it will match the Graph Pad.
Snap block position
to Grid: When moving a block, motif, stencil, embroidery, applique text
with the adjust tool, the upper-left corner of the block snaps to the grid when
released.
Below is an example of the block position grid turned OFF
position, you will notice that the block didn’t line up to exact zero position.
Note: The position can
be found on the Project tool bar. It
will be the first set of numbers. The
side arrows will move your block horizontally or vertically.
|
Grid OFF |
The next images shows you with the Snap Block Position Grid
turned ON. Once the position of the
block was done is made the blocked into position automatically.
|
Grid ON |
Snap block size to
grid: When drag the corner or side handle of a block, motif, stencil,
embroidery, applique text or photo with the Adjust tool the size will snap to
the grid when released. Remember this button doesn’t affect how the block is
set on the grid, only the size while adjusting with the
Adjust tool.
|
Adjust Tool |
Example 1 – Show the Snap Block Size to Grid button
turned OFF. The Snap Grid is now set
to 1”. You will notice that there will be NO
snap to the nearest grid multiple of 1, the size was left hanging in between
the grid lines.
|
Example 1 |
Example 2 – Show the Snap Block Size to Grid button
turned ON. The Snap Grid is still
set to 1”. You will notice that once the adjust tool was released that there
was snap to the nearest grid multiple of 1 the size, block size was now 4” x
5”.
|
Example 2 |
The quilt snap setting, can be a powerful tool when you are
design any custom quilt projects.
Understanding how the settings can make your project more precise. Please remember to refer to your user manual
Chapter 5 for more information on these tools.
